BigRep PLX
BigRep's PLX filament is optimized for large-format 3D printers and consistently delivers high-quality parts with beautiful print surfaces at an attractive price.
Description
BigRep's PLX filament is optimized for large-format 3D printers and consistently delivers high-quality parts at an attractive price. Particularly easy to print, PLX achieves beautiful print surfaces on even the most demanding geometries.
PLX is incredibly versatile, allowing printer settings to be tuned for either higher speeds or beautifully smooth surface finishes. PLX delivers consistent results that make it a reliable material for large-format printing in any industry. Given its balanced performance under various mechanical stresses, PLX is a great all-around filament choice.
As a PLA-based material derived from organic compounds, PLX is biodegradable under the correct conditions. CO2 neutral and environmentally friendly, it has a much lower ecological impact than other plastics derived from fossil fuels.
Highlights
- Most Affordable for Cost Savings
- Highly Consistent Print Results
- Easy to Print for Wide Range of Uses
- Beautiful Surface Quality
- Reduced Environmental Impact
Technical Specification
Compatibility
| Supported BigRep Printers | VIIO 250, STUDIO.2, ONE, PRO |
| Recommended SWITCHPLATES | SWITCHPLATE Select, SWITCHPLATE Prime |
Filament Properties
| Material | Bio Polymer Blend |
| Diameter | 2.85 mm |
| Density (ISO 1183) | 1.24 g/cm³ |
Mechanical Properties
| Tensile Strength (ISO 527) | 48 MPa |
| Tensile Modulus (ISO 178) | 3100 MPa |
| Flexural Strength (ISO 178) | 90 MPa |
| Flexural Modulus (ISO 178) | 2800 MPa |
| Impact Strength, Notched (ISO 527) | 4 kJ/m² |
Thermal Properties
| HDT A - 1.8 MPa (ISO 75) | 56 °C |
| HDT B - 0.45 MPa (ISO 75) | 58 °C |
| Glass Transition Temperature (Tg) (DSC) | 63 °C |
| Melting Temperature (Tm) (DSC) | 170 °C |
Recommended Printing Conditions
| Nozzle Temperature | 190 - 220 °C |
| Print Bed Temperature | 50 - 70 °C |
| Fan Speed | 75 - 100 % |
Other Information
| Drying recommendations | 50 °C for 4 - 6 hours |
| Reach Compliant | Yes |
| RoHS Certified | Yes |
| FDA Compliant | Yes |
Packaging
| Package Weight (Approx.) | 3.2 kg |
The technical data provided herein are for general information and comparison purposes only. Mechanical strength and other properties of parts printed with these materials can vary greatly depending on print settings, user experience, and environmental conditions. We do not guarantee the suitability, safety, or performance of printed parts for any specific purpose. It is the responsibility of the user to test and determine whether the printed parts meet the requirements for their intended use. We do not accept any liability for damage, injury, or loss resulting from the use of this material or from parts made with this material. Please review all available safety information and perform your own testing before using this product in any application.
