Fiberlogy PEI 9085
Fiberlogy PEI 9085 is an industrial-grade 3D printing filament made from ULTEM for incredible strength and stiffness
Prices displayed are tax exclusive. Tax will be calculated during checkout.
Description
Fiberlogy's PEI 9085 is a high-performance filament made from ULTEM™ 9085 resin that boasts incredible strength and stiffness. The unique filament combines the strength of steel and the lightness of aluminum, making it ideal for producing parts that can withstand the toughest of loads. Ideal for applications in the automotive, railroad and aerospace industries, where parts printed with this material can replace metal components.
The material is non-flammable (UL94 V0), has high dielectric strength and good thermal conductivity. It is also resistant to abrasion, high temperatures up to 180 °C, solvents and UV rays.
Tip: PEI 9085 can be processed in 3D printers that are suitable for high temperature materials (PEEK, PEKK, PEI, etc.). To achieve the best printing results, a heated chamber is required to ensure even heat distribution.
Possible applications:
Aviation: Machine parts, structural elements, ventilation elements
Automotive: engine components, spare parts, sensor housings
Electronics: connectors, electronic housings, cable insulation, fuel cell components
Defense industry: covers for weapon systems, lighting housings, housings for optical systems
Note: This item may be subject to extended delivery times
Technical Specification
Compatibility
| Supported BigRep Printers | ALTRA 280 |
Filament Properties
| Material | PEI 9085 |
| Density (ISO 1183) | 1.34 g/cm³ |
| Diameter | 1.75 mm |
| Diameter Tolerance | +/- 0.02 mm |
| Roundness | +0.01 mm |
Mechanical Properties
| Tensile Strength @ Yield (ISO 527) | 88 MPa |
| Tensile Strength @ Break (ISO 527) | 74 MPa |
| Tensile Modulus (ISO 527) | 3050 MPa |
| Elongation @ Yield (ISO 527) | 6.7 % |
| Elongation @ Break (ISO 527) | 50 % |
| Flexural Strength (ISO 178) | 90 MPa |
| Flexural Modulus (ISO 178) | 2750 MPa |
| Izod Impact Strength Notched @ 23°C (ISO 180) | 13 kJ/m² |
| Charpy Impact Strength Notched @ 23°C (ISO 180) | 11 kJ/m² |
Thermal Properties
| Heat Distortion Temperature @ 1.8 MPa (ISO 75) | 152 °C |
| Vicat Softening Temperature (ISO 306) | 173 °C |
| FAA Flammability (FAR 25.853) | <5 |
Recommended Printing Conditions
| Nozzle Temperature | 350 – 380 °C |
| Print Bed Temperature | 160 °C |
| Chamber Temperature | >80 °C |
Other Information
| Reach Compliant | Yes |
| RoHS Compliant | Yes |
Packaging
| Package Weight (Approx.) | 3 kg |
The technical data provided herein are for general information and comparison purposes only. Mechanical strength and other properties of parts printed with these materials can vary greatly depending on print settings, user experience, and environmental conditions. We do not guarantee the suitability, safety, or performance of printed parts for any specific purpose. It is the responsibility of the user to test and determine whether the printed parts meet the requirements for their intended use. We do not accept any liability for damage, injury, or loss resulting from the use of this material or from parts made with this material. Please review all available safety information and perform your own testing before using this product in any application.
