BigRep BVOH
BigRep's water-soluble support material, BVOH drastically reduces post-processing for 3D-printed parts, particularly for complex geometries.
Description
BigRep's BVOH support material is a water-soluble filament that drastically reduces post-processing for 3D-printed parts. Created for use with dual-extruder printers, BigRep BVOH is compatible with a wide range of materials to provide efficient support during the printing process. BVOH is ideal when 3D printing complex geometries where breakaway support be difficult to remove or impossible to access after printing. When the surface appearance of your part is paramount, BigRep BVOH results in better surface quality with less post-processing effort.
BVOH easily dissolves in water, cleanly freeing parts from support structures without manual post-processing. While the dissolving time depends on part geometry and slicing settings, BVOH’s solubility increases with higher water temperature and delivers faster results.
Highlights
- Water Soluble for Easy Removal
- Saves Time Post-Processing
- Nontoxic and Odorless
- Excellent Support Adhesion
- Compatible with Many BigRep Materials
Technical Specification
Compatibility
| Supported BigRep Printers | VIIO 250, STUDIO.2, ONE, PRO |
| Recommended SWITCHPLATES | SWITCHPLATE Classic, SWITCHPLATE Prime |
Filament Properties
| Material | Butenediol Vinyl Alcohol Copolymer |
| Diameter | 2.85 mm |
| Density (ISO 1183) | 1.14 g/cm³ |
Mechanical Properties
| Tensile Strength (ISO 527) | 34 MPa |
| Tensile Modulus (ISO 527) | 2300 MPa |
| Flexural Strength (ISO 178) | 50 MPa |
| Flexural Modulus (ISO 178) | 2200 MPa |
Thermal Properties
| Vicat Softening Temperature | 90 °C |
| Glass Transition Temperature (Tg) (DSC) | 68 °C |
| Melting Temperature (Tm) (DSC) | 175 °C |
Recommended Printing Conditions
| Nozzle Temperature | 190 - 210 °C |
| Print Bed Temperature | 50 - 70 °C |
| Fan Speed | 0 - 100 % |
Other Information
| Drying recommendations | 60 °C for 8 - 12 hours |
| Reach Compliant | Yes |
| RoHS Certified | Yes |
| FDA Compliant | No |
Packaging
| Package Weight (Approx.) | 3.2 kg |
The technical data provided herein are for general information and comparison purposes only. Mechanical strength and other properties of parts printed with these materials can vary greatly depending on print settings, user experience, and environmental conditions. We do not guarantee the suitability, safety, or performance of printed parts for any specific purpose. It is the responsibility of the user to test and determine whether the printed parts meet the requirements for their intended use. We do not accept any liability for damage, injury, or loss resulting from the use of this material or from parts made with this material. Please review all available safety information and perform your own testing before using this product in any application.
